# dpkg --add-architecture i386

$ WINEARCH=win32 WINEPREFIX=~/.wine winecfg

$ WINEARCH=win64 WINEPREFIX=~/.wine64 winecfg

$ WINEPREFIX=~/.wine64 wine game64.exe

Date:   Wed Jul 8 22:22:55 2026 +0200

    ALSA backend: Implement proper device enumeration using snd_device_name_hint()

    Replace the minimal placeholder enumeration that returned hardcoded
    values with proper device enumeration using snd_device_name_hint() API.
    This now correctly enumerates both physical hardware devices and virtual
    devices (BlueALSA, rate converters, plugins) with accurate format capabilities,
    channel counts, and rate ranges queried from actual hardware.

$ cat firefox/media/libcubeb/src/cubeb_alsa.c
/*
 * Copyright © 2011 Mozilla Foundation
 *
 * This program is made available under an ISC-style license.  See the
 * accompanying file LICENSE for details.
 */
#undef NDEBUG
#define _DEFAULT_SOURCE
#define _BSD_SOURCE
#if defined(__NetBSD__)
#define _NETBSD_SOURCE /* timersub() */
#endif
#define _XOPEN_SOURCE 500
#include "cubeb-internal.h"
#include "cubeb/cubeb.h"
#include "cubeb_tracing.h"
#include <alsa/asoundlib.h>
#include <assert.h>
#include <dlfcn.h>
#include <limits.h>
#include <poll.h>
#include <pthread.h>
#include <sys/time.h>
#include <unistd.h>

#ifdef DISABLE_LIBASOUND_DLOPEN
#define WRAP(x) x
#else
#define WRAP(x) (*cubeb_##x)
#define LIBASOUND_API_VISIT(X)                                                 \
  X(snd_config)                                                                \
  X(snd_config_add)                                                            \
  X(snd_config_copy)                                                           \
  X(snd_config_delete)                                                         \
  X(snd_config_get_id)                                                         \
  X(snd_config_get_string)                                                     \
  X(snd_config_imake_integer)                                                  \
  X(snd_config_search)                                                         \
  X(snd_config_search_definition)                                              \
  X(snd_lib_error_set_handler)                                                 \
  X(snd_pcm_avail_update)                                                      \
  X(snd_pcm_close)                                                             \
  X(snd_pcm_delay)                                                             \
  X(snd_pcm_drain)                                                             \
  X(snd_pcm_frames_to_bytes)                                                   \
  X(snd_pcm_get_params)                                                        \
  X(snd_pcm_hw_params_any)                                                     \
  X(snd_pcm_hw_params_get_channels_max)                                        \
  X(snd_pcm_hw_params_get_rate)                                                \
  X(snd_pcm_hw_params_set_rate_near)                                           \
  X(snd_pcm_hw_params_sizeof)                                                  \
  X(snd_pcm_nonblock)                                                          \
  X(snd_pcm_open)                                                              \
  X(snd_pcm_open_lconf)                                                        \
  X(snd_pcm_pause)                                                             \
  X(snd_pcm_poll_descriptors)                                                  \
  X(snd_pcm_poll_descriptors_count)                                            \
  X(snd_pcm_poll_descriptors_revents)                                          \
  X(snd_pcm_readi)                                                             \
  X(snd_pcm_recover)                                                           \
  X(snd_pcm_set_params)                                                        \
  X(snd_pcm_start)                                                             \
  X(snd_pcm_state)                                                             \
  X(snd_pcm_writei)                                                            \
  X(snd_device_name_hint)                                                      \
	X(snd_device_name_get_hint)                                                  \
	X(snd_device_name_free_hint)                                                 \
	X(snd_pcm_hw_params_test_format)                                             \
	X(snd_pcm_hw_params_get_rate_min)                                            \
	X(snd_pcm_hw_params_get_rate_max)                                            \
	X(snd_pcm_hw_params_get_channels_min)                                        \
	X(snd_pcm_hw_params_get_channels_max)

#define MAKE_TYPEDEF(x) static typeof(x) * cubeb_##x;
LIBASOUND_API_VISIT(MAKE_TYPEDEF);
#undef MAKE_TYPEDEF
/* snd_pcm_hw_params_alloca is actually a macro */
#define snd_pcm_hw_params_sizeof cubeb_snd_pcm_hw_params_sizeof
#endif

#define CUBEB_STREAM_MAX 16
#define CUBEB_WATCHDOG_MS 10000

#define CUBEB_ALSA_PCM_NAME "default"

#define ALSA_PA_PLUGIN "ALSA <-> PulseAudio PCM I/O Plugin"

/* ALSA is not thread-safe.  snd_pcm_t instances are individually protected
   by the owning cubeb_stream's mutex.  snd_pcm_t creation and destruction
   is not thread-safe until ALSA 1.0.24 (see alsa-lib.git commit 91c9c8f1),
   so those calls must be wrapped in the following mutex. */
static pthread_mutex_t cubeb_alsa_mutex = PTHREAD_MUTEX_INITIALIZER;
static int cubeb_alsa_error_handler_set = 0;

static struct cubeb_ops const alsa_ops;

struct cubeb {
  struct cubeb_ops const * ops;
  void * libasound;

  pthread_t thread;

  /* Mutex for streams array, must not be held while blocked in poll(2). */
  pthread_mutex_t mutex;

  /* Sparse array of streams managed by this context. */
  cubeb_stream * streams[CUBEB_STREAM_MAX];

  /* fds and nfds are only updated by alsa_run when rebuild is set. */
  struct pollfd * fds;
  nfds_t nfds;
  int rebuild;

  int shutdown;

  /* Control pipe for forcing poll to wake and rebuild fds or recalculate the
   * timeout. */
  int control_fd_read;
  int control_fd_write;

  /* Track number of active streams.  This is limited to CUBEB_STREAM_MAX
     due to resource contraints. */
  unsigned int active_streams;

  /* Local configuration with handle_underrun workaround set for PulseAudio
     ALSA plugin.  Will be NULL if the PA ALSA plugin is not in use or the
     workaround is not required. */
  snd_config_t * local_config;
  int is_pa;
};

enum stream_state { INACTIVE, RUNNING, DRAINING, PROCESSING, ERROR };

struct cubeb_stream {
  /* Note: Must match cubeb_stream layout in cubeb.c. */
  cubeb * context;
  void * user_ptr;
  /**/
  pthread_mutex_t mutex;
  snd_pcm_t * pcm;
  cubeb_data_callback data_callback;
  cubeb_state_callback state_callback;
  snd_pcm_uframes_t stream_position;
  snd_pcm_uframes_t last_position;
  snd_pcm_uframes_t buffer_size;
  cubeb_stream_params params;

  /* Every member after this comment is protected by the owning context's
     mutex rather than the stream's mutex, or is only used on the context's
     run thread. */
  pthread_cond_t cond; /* Signaled when the stream's state is changed. */

  enum stream_state state;

  struct pollfd * saved_fds; /* A copy of the pollfds passed in at init time. */
  struct pollfd *
      fds; /* Pointer to this waitable's pollfds within struct cubeb's fds. */
  nfds_t nfds;

  struct timeval drain_timeout;

  /* XXX: Horrible hack -- if an active stream has been idle for
     CUBEB_WATCHDOG_MS it will be disabled and the error callback will be
     called.  This works around a bug seen with older versions of ALSA and
     PulseAudio where streams would stop requesting new data despite still
     being logically active and playing. */
  struct timeval last_activity;
  float volume;

  char * buffer;
  snd_pcm_uframes_t bufframes;
  snd_pcm_stream_t stream_type;

  struct cubeb_stream * other_stream;
};

static int
any_revents(struct pollfd * fds, nfds_t nfds)
{
  nfds_t i;

  for (i = 0; i < nfds; ++i) {
    if (fds[i].revents) {
      return 1;
    }
  }

  return 0;
}

static int
cmp_timeval(struct timeval * a, struct timeval * b)
{
  if (a->tv_sec == b->tv_sec) {
    if (a->tv_usec == b->tv_usec) {
      return 0;
    }
    return a->tv_usec > b->tv_usec ? 1 : -1;
  }
  return a->tv_sec > b->tv_sec ? 1 : -1;
}

static int
timeval_to_relative_ms(struct timeval * tv)
{
  struct timeval now;
  struct timeval dt;
  long long t;
  int r;

  gettimeofday(&now, NULL);
  r = cmp_timeval(tv, &now);
  if (r >= 0) {
    timersub(tv, &now, &dt);
  } else {
    timersub(&now, tv, &dt);
  }
  t = dt.tv_sec;
  t *= 1000;
  t += (dt.tv_usec + 500) / 1000;

  if (t > INT_MAX) {
    t = INT_MAX;
  } else if (t < INT_MIN) {
    t = INT_MIN;
  }

  return r >= 0 ? t : -t;
}

static int
ms_until(struct timeval * tv)
{
  return timeval_to_relative_ms(tv);
}

static int
ms_since(struct timeval * tv)
{
  return -timeval_to_relative_ms(tv);
}

static void
rebuild(cubeb * ctx)
{
  nfds_t nfds;
  int i;
  nfds_t j;
  cubeb_stream * stm;

  assert(ctx->rebuild);

  /* Always count context's control pipe fd. */
  nfds = 1;
  for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
    stm = ctx->streams[i];
    if (stm) {
      stm->fds = NULL;
      if (stm->state == RUNNING) {
        nfds += stm->nfds;
      }
    }
  }

  free(ctx->fds);
  ctx->fds = calloc(nfds, sizeof(struct pollfd));
  assert(ctx->fds);
  ctx->nfds = nfds;

  /* Include context's control pipe fd. */
  ctx->fds[0].fd = ctx->control_fd_read;
  ctx->fds[0].events = POLLIN | POLLERR;

  for (i = 0, j = 1; i < CUBEB_STREAM_MAX; ++i) {
    stm = ctx->streams[i];
    if (stm && stm->state == RUNNING) {
      memcpy(&ctx->fds[j], stm->saved_fds, stm->nfds * sizeof(struct pollfd));
      stm->fds = &ctx->fds[j];
      j += stm->nfds;
    }
  }

  ctx->rebuild = 0;
}

static void
poll_wake(cubeb * ctx)
{
  if (write(ctx->control_fd_write, "x", 1) < 0) {
    /* ignore write error */
  }
}

static void
set_timeout(struct timeval * timeout, unsigned int ms)
{
  gettimeofday(timeout, NULL);
  timeout->tv_sec += ms / 1000;
  timeout->tv_usec += (ms % 1000) * 1000;
}

static void
stream_buffer_decrement(cubeb_stream * stm, long count)
{
  if (count < 0 || (snd_pcm_uframes_t)count > stm->bufframes) {
    count = stm->bufframes;
  }
  char * bufremains =
      stm->buffer + WRAP(snd_pcm_frames_to_bytes)(stm->pcm, count);
  memmove(stm->buffer, bufremains,
          WRAP(snd_pcm_frames_to_bytes)(stm->pcm, stm->bufframes - count));
  stm->bufframes -= count;
}

static void
alsa_set_stream_state(cubeb_stream * stm, enum stream_state state)
{
  cubeb * ctx;
  int r;

  ctx = stm->context;
  stm->state = state;
  r = pthread_cond_broadcast(&stm->cond);
  assert(r == 0);
  ctx->rebuild = 1;
  poll_wake(ctx);
}

static void
alsa_set_draining(cubeb_stream * stm)
{
  alsa_set_stream_state(stm, DRAINING);
  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK && stm->other_stream &&
      stm->other_stream->state == RUNNING) {
    alsa_set_stream_state(stm->other_stream, DRAINING);
  }
}

static enum stream_state
alsa_process_stream(cubeb_stream * stm, int other_stream_running)
{
  unsigned short revents;
  snd_pcm_sframes_t avail;
  int draining;

  draining = 0;

  pthread_mutex_lock(&stm->mutex);

  /* Call _poll_descriptors_revents() even if we don't use it
     to let underlying plugins clear null events.  Otherwise poll()
     may wake up again and again, producing unnecessary CPU usage. */
  WRAP(snd_pcm_poll_descriptors_revents)
  (stm->pcm, stm->fds, stm->nfds, &revents);

  avail = WRAP(snd_pcm_avail_update)(stm->pcm);

  /* Got null event? Bail and wait for another wakeup. */
  if (avail == 0) {
    pthread_mutex_unlock(&stm->mutex);
    return RUNNING;
  }

  /* This could happen if we were suspended with SIGSTOP/Ctrl+Z for a long time.
   */
  if ((unsigned int)avail > stm->buffer_size) {
    avail = stm->buffer_size;
  }

  /* Capture: Read available frames */
  if (stm->stream_type == SND_PCM_STREAM_CAPTURE && avail > 0) {
    snd_pcm_sframes_t got;

    if (avail + stm->bufframes > stm->buffer_size) {
      /* Buffer overflow. Skip and overwrite with new data. */
      stm->bufframes = 0;
      // TODO: should it be marked as DRAINING?
    }

    got = WRAP(snd_pcm_readi)(stm->pcm, stm->buffer + stm->bufframes, avail);

    if (got < 0) {
      avail = got; // the error handler below will recover us
    } else {
      stm->bufframes += got;
      stm->stream_position += got;

      gettimeofday(&stm->last_activity, NULL);
    }
  }

  /* Capture: Pass read frames to callback function */
  if (stm->stream_type == SND_PCM_STREAM_CAPTURE && stm->bufframes > 0 &&
      (!stm->other_stream ||
       stm->other_stream->bufframes < stm->other_stream->buffer_size)) {
    snd_pcm_sframes_t wrote = stm->bufframes;
    snd_pcm_sframes_t requested;
    struct cubeb_stream * mainstm = stm->other_stream ? stm->other_stream : stm;
    void * other_buffer = stm->other_stream ? stm->other_stream->buffer +
                                                  stm->other_stream->bufframes
                                            : NULL;

    /* Correct write size to the other stream available space */
    if (stm->other_stream &&
        wrote > (snd_pcm_sframes_t)(stm->other_stream->buffer_size -
                                    stm->other_stream->bufframes)) {
      wrote = stm->other_stream->buffer_size - stm->other_stream->bufframes;
    }

    requested = wrote;
    pthread_mutex_unlock(&stm->mutex);
    wrote = stm->data_callback(mainstm, stm->user_ptr, stm->buffer,
                               other_buffer, wrote);
    pthread_mutex_lock(&stm->mutex);

    if (wrote < 0) {
      avail = wrote; // the error handler below will recover us
    } else {
      stream_buffer_decrement(stm, wrote);

      if (stm->other_stream) {
        stm->other_stream->bufframes += wrote;
      }
      if (wrote < requested) {
        if (!stm->other_stream) {
          pthread_mutex_unlock(&stm->mutex);
          return INACTIVE;
        }
        draining = 1;
        set_timeout(&stm->drain_timeout, 0);
      }
    }
  }

  /* Playback: Don't have enough data? Let's ask for more. */
  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK &&
      avail > (snd_pcm_sframes_t)stm->bufframes &&
      (!stm->other_stream ||
       (other_stream_running && stm->other_stream->bufframes > 0))) {
    long got = avail - stm->bufframes;
    void * other_buffer = stm->other_stream ? stm->other_stream->buffer : NULL;
    char * buftail =
        stm->buffer + WRAP(snd_pcm_frames_to_bytes)(stm->pcm, stm->bufframes);
    long requested;

    /* Correct read size to the other stream available frames */
    if (stm->other_stream &&
        got > (snd_pcm_sframes_t)stm->other_stream->bufframes) {
      got = stm->other_stream->bufframes;
    }

    requested = got;
    pthread_mutex_unlock(&stm->mutex);
    got = stm->data_callback(stm, stm->user_ptr, other_buffer, buftail, got);
    pthread_mutex_lock(&stm->mutex);

    if (got < 0) {
      avail = got; // the error handler below will recover us
    } else {
      stm->bufframes += got;

      if (stm->other_stream) {
        stream_buffer_decrement(stm->other_stream, got);
      }
      if (got < requested) {
        draining = 1;
      }
    }
  }

  /* Playback: Still don't have enough data? Add some silence. */
  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK &&
      avail > (snd_pcm_sframes_t)stm->bufframes) {
    long drain_frames = avail - stm->bufframes;
    double drain_time = (double)drain_frames / stm->params.rate;

    char * buftail =
        stm->buffer + WRAP(snd_pcm_frames_to_bytes)(stm->pcm, stm->bufframes);
    memset(buftail, 0, WRAP(snd_pcm_frames_to_bytes)(stm->pcm, drain_frames));
    stm->bufframes = avail;

    /* Mark as draining, unless we're waiting for capture */
    if (!stm->other_stream || draining || stm->other_stream->bufframes > 0) {
      set_timeout(&stm->drain_timeout, drain_time * 1000);

      draining = 1;
    }
  }

  /* Playback: Have enough data and no errors. Let's write it out. */
  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK && avail > 0) {
    snd_pcm_sframes_t wrote;

    if (stm->params.format == CUBEB_SAMPLE_FLOAT32NE) {
      float * b = (float *)stm->buffer;
      for (uint32_t i = 0; i < avail * stm->params.channels; i++) {
        b[i] *= stm->volume;
      }
    } else {
      short * b = (short *)stm->buffer;
      for (uint32_t i = 0; i < avail * stm->params.channels; i++) {
        b[i] *= stm->volume;
      }
    }

    wrote = WRAP(snd_pcm_writei)(stm->pcm, stm->buffer, avail);
    if (wrote < 0) {
      avail = wrote; // the error handler below will recover us
    } else {
      stream_buffer_decrement(stm, wrote);

      stm->stream_position += wrote;
      gettimeofday(&stm->last_activity, NULL);
    }
  }

  /* Got some error? Let's try to recover the stream. */
  if (avail < 0) {
    avail = WRAP(snd_pcm_recover)(stm->pcm, avail, 0);

    /* Capture pcm must be started after initial setup/recover */
    if (avail >= 0 && stm->stream_type == SND_PCM_STREAM_CAPTURE &&
        WRAP(snd_pcm_state)(stm->pcm) == SND_PCM_STATE_PREPARED) {
      avail = WRAP(snd_pcm_start)(stm->pcm);
    }
  }

  /* Failed to recover, this stream must be broken. */
  if (avail < 0) {
    pthread_mutex_unlock(&stm->mutex);
    stm->state_callback(stm, stm->user_ptr, CUBEB_STATE_ERROR);
    return ERROR;
  }

  pthread_mutex_unlock(&stm->mutex);
  return draining ? DRAINING : RUNNING;
}

static int
alsa_run(cubeb * ctx)
{
  int r;
  int timeout;
  int i;
  char dummy;
  cubeb_stream * stm;
  enum stream_state state;

  pthread_mutex_lock(&ctx->mutex);

  if (ctx->rebuild) {
    rebuild(ctx);
  }

  /* Wake up at least once per second for the watchdog. */
  timeout = 1000;
  for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
    stm = ctx->streams[i];
    if (stm && stm->state == DRAINING) {
      r = ms_until(&stm->drain_timeout);
      if (r < 0) {
        r = 0;
      }
      if (timeout > r) {
        timeout = r;
      }
    }
  }

  pthread_mutex_unlock(&ctx->mutex);
  r = poll(ctx->fds, ctx->nfds, timeout);
  pthread_mutex_lock(&ctx->mutex);

  if (r > 0) {
    if (ctx->fds[0].revents & POLLIN) {
      if (read(ctx->control_fd_read, &dummy, 1) < 0) {
        /* ignore read error */
      }

      if (ctx->shutdown) {
        pthread_mutex_unlock(&ctx->mutex);
        return -1;
      }
    }

    for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
      stm = ctx->streams[i];
      /* We can't use snd_pcm_poll_descriptors_revents here because of
         https://github.com/kinetiknz/cubeb/issues/135. */
      if (stm && stm->state == RUNNING && stm->fds &&
          any_revents(stm->fds, stm->nfds)) {
        int other_stream_running =
            !stm->other_stream || stm->other_stream->state == RUNNING;
        alsa_set_stream_state(stm, PROCESSING);
        pthread_mutex_unlock(&ctx->mutex);
        state = alsa_process_stream(stm, other_stream_running);
        pthread_mutex_lock(&ctx->mutex);
        if (state == DRAINING) {
          alsa_set_draining(stm);
        } else if (state == INACTIVE) {
          alsa_set_stream_state(stm, state);
          stm->state_callback(stm, stm->user_ptr, CUBEB_STATE_STOPPED);
        } else {
          alsa_set_stream_state(stm, state);
        }
      }
    }
  } else if (r == 0) {
    for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
      stm = ctx->streams[i];
      if (stm) {
        if (stm->state == DRAINING && ms_since(&stm->drain_timeout) >= 0) {
          alsa_set_stream_state(stm, INACTIVE);
          if (!stm->other_stream ||
              stm->stream_type == SND_PCM_STREAM_PLAYBACK) {
            stm->state_callback(stm, stm->user_ptr, CUBEB_STATE_DRAINED);
          }
        } else if (stm->state == RUNNING &&
                   ms_since(&stm->last_activity) > CUBEB_WATCHDOG_MS) {
          alsa_set_stream_state(stm, ERROR);
          stm->state_callback(stm, stm->user_ptr, CUBEB_STATE_ERROR);
        }
      }
    }
  }

  pthread_mutex_unlock(&ctx->mutex);

  return 0;
}

static void *
alsa_run_thread(void * context)
{
  cubeb * ctx = context;
  int r;

  CUBEB_REGISTER_THREAD("cubeb rendering thread");

  do {
    r = alsa_run(ctx);
  } while (r >= 0);

  CUBEB_UNREGISTER_THREAD();

  return NULL;
}

static snd_config_t *
get_slave_pcm_node(snd_config_t * lconf, snd_config_t * root_pcm)
{
  int r;
  snd_config_t * slave_pcm;
  snd_config_t * slave_def;
  snd_config_t * pcm;
  char const * string;
  char node_name[64];

  slave_def = NULL;

  r = WRAP(snd_config_search)(root_pcm, "slave", &slave_pcm);
  if (r < 0) {
    return NULL;
  }

  r = WRAP(snd_config_get_string)(slave_pcm, &string);
  if (r >= 0) {
    r = WRAP(snd_config_search_definition)(lconf, "pcm_slave", string,
                                           &slave_def);
    if (r < 0) {
      return NULL;
    }
  }

  do {
    r = WRAP(snd_config_search)(slave_def ? slave_def : slave_pcm, "pcm", &pcm);
    if (r < 0) {
      break;
    }

    r = WRAP(snd_config_get_string)(slave_def ? slave_def : slave_pcm, &string);
    if (r < 0) {
      break;
    }

    r = snprintf(node_name, sizeof(node_name), "pcm.%s", string);
    if (r < 0 || r > (int)sizeof(node_name)) {
      break;
    }
    r = WRAP(snd_config_search)(lconf, node_name, &pcm);
    if (r < 0) {
      break;
    }

    return pcm;
  } while (0);

  if (slave_def) {
    WRAP(snd_config_delete)(slave_def);
  }

  return NULL;
}

/* Work around PulseAudio ALSA plugin bug where the PA server forces a
   higher than requested latency, but the plugin does not update its (and
   ALSA's) internal state to reflect that, leading to an immediate underrun
   situation.  Inspired by WINE's make_handle_underrun_config.
   Reference: http://mailman.alsa-project.org/pipermail/alsa-devel/2012-July/05
 */
static snd_config_t *
init_local_config_with_workaround(char const * pcm_name)
{
  int r;
  snd_config_t * lconf;
  snd_config_t * pcm_node;
  snd_config_t * node;
  char const * string;
  char node_name[64];

  lconf = NULL;

  if (WRAP(snd_config) == NULL) {
    return NULL;
  }

  r = WRAP(snd_config_copy)(&lconf, WRAP(snd_config));
  if (r < 0) {
    return NULL;
  }

  do {
    r = WRAP(snd_config_search_definition)(lconf, "pcm", pcm_name, &pcm_node);
    if (r < 0) {
      break;
    }

    r = WRAP(snd_config_get_id)(pcm_node, &string);
    if (r < 0) {
      break;
    }

    r = snprintf(node_name, sizeof(node_name), "pcm.%s", string);
    if (r < 0 || r > (int)sizeof(node_name)) {
      break;
    }
    r = WRAP(snd_config_search)(lconf, node_name, &pcm_node);
    if (r < 0) {
      break;
    }

    /* If this PCM has a slave, walk the slave configurations until we reach the
     * bottom. */
    while ((node = get_slave_pcm_node(lconf, pcm_node)) != NULL) {
      pcm_node = node;
    }

    /* Fetch the PCM node's type, and bail out if it's not the PulseAudio
     * plugin. */
    r = WRAP(snd_config_search)(pcm_node, "type", &node);
    if (r < 0) {
      break;
    }

    r = WRAP(snd_config_get_string)(node, &string);
    if (r < 0) {
      break;
    }

    if (strcmp(string, "pulse") != 0) {
      break;
    }

    /* Don't clobber an explicit existing handle_underrun value, set it only
       if it doesn't already exist. */
    r = WRAP(snd_config_search)(pcm_node, "handle_underrun", &node);
    if (r != -ENOENT) {
      break;
    }

    /* Disable pcm_pulse's asynchronous underrun handling. */
    r = WRAP(snd_config_imake_integer)(&node, "handle_underrun", 0);
    if (r < 0) {
      break;
    }

    r = WRAP(snd_config_add)(pcm_node, node);
    if (r < 0) {
      break;
    }

    return lconf;
  } while (0);

  WRAP(snd_config_delete)(lconf);

  return NULL;
}

static int
alsa_locked_pcm_open(snd_pcm_t ** pcm, char const * pcm_name,
                     snd_pcm_stream_t stream, snd_config_t * local_config)
{
  int r;

  pthread_mutex_lock(&cubeb_alsa_mutex);
  if (local_config) {
    r = WRAP(snd_pcm_open_lconf)(pcm, pcm_name, stream, SND_PCM_NONBLOCK,
                                 local_config);
  } else {
    r = WRAP(snd_pcm_open)(pcm, pcm_name, stream, SND_PCM_NONBLOCK);
  }
  pthread_mutex_unlock(&cubeb_alsa_mutex);

  return r;
}

static int
alsa_locked_pcm_close(snd_pcm_t * pcm)
{
  int r;

  pthread_mutex_lock(&cubeb_alsa_mutex);
  r = WRAP(snd_pcm_close)(pcm);
  pthread_mutex_unlock(&cubeb_alsa_mutex);

  return r;
}

static int
alsa_register_stream(cubeb * ctx, cubeb_stream * stm)
{
  int i;

  pthread_mutex_lock(&ctx->mutex);
  for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
    if (!ctx->streams[i]) {
      ctx->streams[i] = stm;
      break;
    }
  }
  pthread_mutex_unlock(&ctx->mutex);

  return i == CUBEB_STREAM_MAX;
}

static void
alsa_unregister_stream(cubeb_stream * stm)
{
  cubeb * ctx;
  int i;

  ctx = stm->context;

  pthread_mutex_lock(&ctx->mutex);
  for (i = 0; i < CUBEB_STREAM_MAX; ++i) {
    if (ctx->streams[i] == stm) {
      ctx->streams[i] = NULL;
      break;
    }
  }
  pthread_mutex_unlock(&ctx->mutex);
}

static void
silent_error_handler(char const * file, int line, char const * function,
                     int err, char const * fmt, ...)
{
  (void)file;
  (void)line;
  (void)function;
  (void)err;
  (void)fmt;
}

/*static*/ int
alsa_init(cubeb ** context, char const * context_name)
{
  (void)context_name;
  void * libasound = NULL;
  cubeb * ctx;
  int r;
  int i;
  int fd[2];
  pthread_attr_t attr;
  snd_pcm_t * dummy;

  assert(context);
  *context = NULL;

#ifndef DISABLE_LIBASOUND_DLOPEN
  libasound = dlopen("libasound.so.2", RTLD_LAZY);
  if (!libasound) {
    libasound = dlopen("libasound.so", RTLD_LAZY);
    if (!libasound) {
      return CUBEB_ERROR;
    }
  }

#define LOAD(x)                                                                \
  {                                                                            \
    cubeb_##x = dlsym(libasound, #x);                                          \
    if (!cubeb_##x) {                                                          \
      dlclose(libasound);                                                      \
      return CUBEB_ERROR;                                                      \
    }                                                                          \
  }

  LIBASOUND_API_VISIT(LOAD);
#undef LOAD
#endif

  pthread_mutex_lock(&cubeb_alsa_mutex);
  if (!cubeb_alsa_error_handler_set) {
    WRAP(snd_lib_error_set_handler)(silent_error_handler);
    cubeb_alsa_error_handler_set = 1;
  }
  pthread_mutex_unlock(&cubeb_alsa_mutex);

  ctx = calloc(1, sizeof(*ctx));
  assert(ctx);

  ctx->ops = &alsa_ops;
  ctx->libasound = libasound;

  r = pthread_mutex_init(&ctx->mutex, NULL);
  assert(r == 0);

  r = pipe(fd);
  assert(r == 0);

  for (i = 0; i < 2; ++i) {
    fcntl(fd[i], F_SETFD, fcntl(fd[i], F_GETFD) | FD_CLOEXEC);
    fcntl(fd[i], F_SETFL, fcntl(fd[i], F_GETFL) | O_NONBLOCK);
  }

  ctx->control_fd_read = fd[0];
  ctx->control_fd_write = fd[1];

  /* Force an early rebuild when alsa_run is first called to ensure fds and
     nfds have been initialized. */
  ctx->rebuild = 1;

  r = pthread_attr_init(&attr);
  assert(r == 0);

  r = pthread_attr_setstacksize(&attr, 256 * 1024);
  assert(r == 0);

  r = pthread_create(&ctx->thread, &attr, alsa_run_thread, ctx);
  assert(r == 0);

  r = pthread_attr_destroy(&attr);
  assert(r == 0);

  /* Open a dummy PCM to force the configuration space to be evaluated so that
     init_local_config_with_workaround can find and modify the default node. */
  r = alsa_locked_pcm_open(&dummy, CUBEB_ALSA_PCM_NAME, SND_PCM_STREAM_PLAYBACK,
                           NULL);
  if (r >= 0) {
    alsa_locked_pcm_close(dummy);
  }
  ctx->is_pa = 0;
  pthread_mutex_lock(&cubeb_alsa_mutex);
  ctx->local_config = init_local_config_with_workaround(CUBEB_ALSA_PCM_NAME);
  pthread_mutex_unlock(&cubeb_alsa_mutex);
  if (ctx->local_config) {
    ctx->is_pa = 1;
    r = alsa_locked_pcm_open(&dummy, CUBEB_ALSA_PCM_NAME,
                             SND_PCM_STREAM_PLAYBACK, ctx->local_config);
    /* If we got a local_config, we found a PA PCM.  If opening a PCM with that
       config fails with EINVAL, the PA PCM is too old for this workaround. */
    if (r == -EINVAL) {
      pthread_mutex_lock(&cubeb_alsa_mutex);
      WRAP(snd_config_delete)(ctx->local_config);
      pthread_mutex_unlock(&cubeb_alsa_mutex);
      ctx->local_config = NULL;
    } else if (r >= 0) {
      alsa_locked_pcm_close(dummy);
    }
  }

  *context = ctx;

  return CUBEB_OK;
}

static char const *
alsa_get_backend_id(cubeb * ctx)
{
  (void)ctx;
  return "alsa";
}

static void
alsa_destroy(cubeb * ctx)
{
  int r;

  assert(ctx);

  pthread_mutex_lock(&ctx->mutex);
  ctx->shutdown = 1;
  poll_wake(ctx);
  pthread_mutex_unlock(&ctx->mutex);

  r = pthread_join(ctx->thread, NULL);
  assert(r == 0);

  close(ctx->control_fd_read);
  close(ctx->control_fd_write);
  pthread_mutex_destroy(&ctx->mutex);
  free(ctx->fds);

  if (ctx->local_config) {
    pthread_mutex_lock(&cubeb_alsa_mutex);
    WRAP(snd_config_delete)(ctx->local_config);
    pthread_mutex_unlock(&cubeb_alsa_mutex);
  }
#ifndef DISABLE_LIBASOUND_DLOPEN
  if (ctx->libasound) {
    dlclose(ctx->libasound);
  }
#endif
  free(ctx);
}

static void
alsa_stream_destroy(cubeb_stream * stm);

static int
alsa_stream_init_single(cubeb * ctx, cubeb_stream ** stream,
                        char const * stream_name, snd_pcm_stream_t stream_type,
                        cubeb_devid deviceid,
                        cubeb_stream_params * stream_params,
                        unsigned int latency_frames,
                        cubeb_data_callback data_callback,
                        cubeb_state_callback state_callback, void * user_ptr)
{
  (void)stream_name;
  cubeb_stream * stm;
  int r;
  snd_pcm_format_t format;
  snd_pcm_uframes_t period_size;
  int latency_us = 0;
  char const * pcm_name =
      deviceid ? (char const *)deviceid : CUBEB_ALSA_PCM_NAME;

  assert(ctx && stream);

  *stream = NULL;

  if (stream_params->prefs & CUBEB_STREAM_PREF_LOOPBACK) {
    return CUBEB_ERROR_NOT_SUPPORTED;
  }

  switch (stream_params->format) {
  case CUBEB_SAMPLE_S16LE:
    format = SND_PCM_FORMAT_S16_LE;
    break;
  case CUBEB_SAMPLE_S16BE:
    format = SND_PCM_FORMAT_S16_BE;
    break;
  case CUBEB_SAMPLE_FLOAT32LE:
    format = SND_PCM_FORMAT_FLOAT_LE;
    break;
  case CUBEB_SAMPLE_FLOAT32BE:
    format = SND_PCM_FORMAT_FLOAT_BE;
    break;
  default:
    return CUBEB_ERROR_INVALID_FORMAT;
  }

  pthread_mutex_lock(&ctx->mutex);
  if (ctx->active_streams >= CUBEB_STREAM_MAX) {
    pthread_mutex_unlock(&ctx->mutex);
    return CUBEB_ERROR;
  }
  ctx->active_streams += 1;
  pthread_mutex_unlock(&ctx->mutex);

  stm = calloc(1, sizeof(*stm));
  assert(stm);

  stm->context = ctx;
  stm->data_callback = data_callback;
  stm->state_callback = state_callback;
  stm->user_ptr = user_ptr;
  stm->params = *stream_params;
  stm->state = INACTIVE;
  stm->volume = 1.0;
  stm->buffer = NULL;
  stm->bufframes = 0;
  stm->stream_type = stream_type;
  stm->other_stream = NULL;

  r = pthread_mutex_init(&stm->mutex, NULL);
  assert(r == 0);

  r = pthread_cond_init(&stm->cond, NULL);
  assert(r == 0);

  r = alsa_locked_pcm_open(&stm->pcm, pcm_name, stm->stream_type,
                           ctx->local_config);
  if (r < 0) {
    alsa_stream_destroy(stm);
    return CUBEB_ERROR;
  }

  r = WRAP(snd_pcm_nonblock)(stm->pcm, 1);
  assert(r == 0);

  latency_us = latency_frames * 1e6 / stm->params.rate;

  /* Ugly hack: the PA ALSA plugin allows buffer configurations that can't
     possibly work.  See https://bugzilla.mozilla.org/show_bug.cgi?id=761274.
     Only resort to this hack if the handle_underrun workaround failed. */
  if (!ctx->local_config && ctx->is_pa) {
    const int min_latency = 5e5;
    latency_us = latency_us < min_latency ? min_latency : latency_us;
  }

  r = WRAP(snd_pcm_set_params)(stm->pcm, format, SND_PCM_ACCESS_RW_INTERLEAVED,
                               stm->params.channels, stm->params.rate, 1,
                               latency_us);
  if (r < 0) {
    alsa_stream_destroy(stm);
    return CUBEB_ERROR_INVALID_FORMAT;
  }

  r = WRAP(snd_pcm_get_params)(stm->pcm, &stm->buffer_size, &period_size);
  assert(r == 0);

  /* Double internal buffer size to have enough space when waiting for the other
   * side of duplex connection */
  stm->buffer_size *= 2;
  stm->buffer =
      calloc(1, WRAP(snd_pcm_frames_to_bytes)(stm->pcm, stm->buffer_size));
  assert(stm->buffer);

  stm->nfds = WRAP(snd_pcm_poll_descriptors_count)(stm->pcm);
  assert(stm->nfds > 0);

  stm->saved_fds = calloc(stm->nfds, sizeof(struct pollfd));
  assert(stm->saved_fds);
  r = WRAP(snd_pcm_poll_descriptors)(stm->pcm, stm->saved_fds, stm->nfds);
  assert((nfds_t)r == stm->nfds);

  if (alsa_register_stream(ctx, stm) != 0) {
    alsa_stream_destroy(stm);
    return CUBEB_ERROR;
  }

  *stream = stm;

  return CUBEB_OK;
}

static int
alsa_stream_init(cubeb * ctx, cubeb_stream ** stream, char const * stream_name,
                 cubeb_devid input_device,
                 cubeb_stream_params * input_stream_params,
                 cubeb_devid output_device,
                 cubeb_stream_params * output_stream_params,
                 unsigned int latency_frames, cubeb_data_callback data_callback,
                 cubeb_state_callback state_callback, void * user_ptr)
{
  int result = CUBEB_OK;
  cubeb_stream *instm = NULL, *outstm = NULL;

  if (result == CUBEB_OK && input_stream_params) {
    result = alsa_stream_init_single(ctx, &instm, stream_name,
                                     SND_PCM_STREAM_CAPTURE, input_device,
                                     input_stream_params, latency_frames,
                                     data_callback, state_callback, user_ptr);
  }

  if (result == CUBEB_OK && output_stream_params) {
    result = alsa_stream_init_single(ctx, &outstm, stream_name,
                                     SND_PCM_STREAM_PLAYBACK, output_device,
                                     output_stream_params, latency_frames,
                                     data_callback, state_callback, user_ptr);
  }

  if (result == CUBEB_OK && input_stream_params && output_stream_params) {
    instm->other_stream = outstm;
    outstm->other_stream = instm;
  }

  if (result != CUBEB_OK && instm) {
    alsa_stream_destroy(instm);
  }

  *stream = outstm ? outstm : instm;

  return result;
}

static void
alsa_stream_destroy(cubeb_stream * stm)
{
  int r;
  cubeb * ctx;

  assert(stm && (stm->state == INACTIVE || stm->state == ERROR ||
                 stm->state == DRAINING));

  ctx = stm->context;

  if (stm->other_stream) {
    stm->other_stream->other_stream = NULL; // to stop infinite recursion
    alsa_stream_destroy(stm->other_stream);
  }

  pthread_mutex_lock(&stm->mutex);
  if (stm->pcm) {
    if (stm->state == DRAINING) {
      WRAP(snd_pcm_drain)(stm->pcm);
    }
    alsa_locked_pcm_close(stm->pcm);
    stm->pcm = NULL;
  }
  free(stm->saved_fds);
  pthread_mutex_unlock(&stm->mutex);
  pthread_mutex_destroy(&stm->mutex);

  r = pthread_cond_destroy(&stm->cond);
  assert(r == 0);

  alsa_unregister_stream(stm);

  pthread_mutex_lock(&ctx->mutex);
  assert(ctx->active_streams >= 1);
  ctx->active_streams -= 1;
  pthread_mutex_unlock(&ctx->mutex);

  free(stm->buffer);

  free(stm);
}

static int
alsa_get_max_channel_count(cubeb * ctx, uint32_t * max_channels)
{
  int r;
  cubeb_stream * stm;
  snd_pcm_hw_params_t * hw_params;
  cubeb_stream_params params;
  params.rate = 44100;
  params.format = CUBEB_SAMPLE_FLOAT32NE;
  params.channels = 2;

  snd_pcm_hw_params_alloca(&hw_params);

  assert(ctx);

  r = alsa_stream_init(ctx, &stm, "", NULL, NULL, NULL, &params, 100, NULL,
                       NULL, NULL);
  if (r != CUBEB_OK) {
    return CUBEB_ERROR;
  }

  assert(stm);

  r = WRAP(snd_pcm_hw_params_any)(stm->pcm, hw_params);
  if (r < 0) {
    return CUBEB_ERROR;
  }

  r = WRAP(snd_pcm_hw_params_get_channels_max)(hw_params, max_channels);
  if (r < 0) {
    return CUBEB_ERROR;
  }

  /* Cap at reasonable maximum to filter driver placeholder values */
  if (*max_channels > 64) {
    *max_channels = 64;
  }

  alsa_stream_destroy(stm);

  return CUBEB_OK;
}

static int
alsa_get_preferred_sample_rate(cubeb * ctx, uint32_t * rate)
{
  (void)ctx;
  int r, dir;
  snd_pcm_t * pcm;
  snd_pcm_hw_params_t * hw_params;

  snd_pcm_hw_params_alloca(&hw_params);

  /* get a pcm, disabling resampling, so we get a rate the
   * hardware/dmix/pulse/etc. supports. */
  r = WRAP(snd_pcm_open)(&pcm, CUBEB_ALSA_PCM_NAME, SND_PCM_STREAM_PLAYBACK,
                         SND_PCM_NO_AUTO_RESAMPLE);
  if (r < 0) {
    return CUBEB_ERROR;
  }

  r = WRAP(snd_pcm_hw_params_any)(pcm, hw_params);
  if (r < 0) {
    WRAP(snd_pcm_close)(pcm);
    return CUBEB_ERROR;
  }

  r = WRAP(snd_pcm_hw_params_get_rate)(hw_params, rate, &dir);
  if (r >= 0) {
    /* There is a default rate: use it. */
    WRAP(snd_pcm_close)(pcm);
    return CUBEB_OK;
  }

  /* Use a common rate, alsa may adjust it based on hw/etc. capabilities. */
  *rate = 44100;

  r = WRAP(snd_pcm_hw_params_set_rate_near)(pcm, hw_params, rate, NULL);
  if (r < 0) {
    WRAP(snd_pcm_close)(pcm);
    return CUBEB_ERROR;
  }

  WRAP(snd_pcm_close)(pcm);

  return CUBEB_OK;
}

static int
alsa_get_min_latency(cubeb * ctx, cubeb_stream_params params,
                     uint32_t * latency_frames)
{
  (void)ctx;
  /* 40ms is found to be an acceptable minimum, even on a super low-end
   * machine. */
  *latency_frames = 40 * params.rate / 1000;

  return CUBEB_OK;
}

static int
alsa_stream_start(cubeb_stream * stm)
{
  cubeb * ctx;

  assert(stm);
  ctx = stm->context;

  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK && stm->other_stream) {
    int r = alsa_stream_start(stm->other_stream);
    if (r != CUBEB_OK)
      return r;
  }

  pthread_mutex_lock(&stm->mutex);
  /* Capture pcm must be started after initial setup/recover */
  if (stm->stream_type == SND_PCM_STREAM_CAPTURE &&
      WRAP(snd_pcm_state)(stm->pcm) == SND_PCM_STATE_PREPARED) {
    WRAP(snd_pcm_start)(stm->pcm);
  }
  WRAP(snd_pcm_pause)(stm->pcm, 0);
  gettimeofday(&stm->last_activity, NULL);
  pthread_mutex_unlock(&stm->mutex);

  pthread_mutex_lock(&ctx->mutex);
  if (stm->state != INACTIVE) {
    pthread_mutex_unlock(&ctx->mutex);
    return CUBEB_ERROR;
  }
  alsa_set_stream_state(stm, RUNNING);
  pthread_mutex_unlock(&ctx->mutex);

  return CUBEB_OK;
}

static int
alsa_stream_stop(cubeb_stream * stm)
{
  cubeb * ctx;
  int r;

  assert(stm);
  ctx = stm->context;

  if (stm->stream_type == SND_PCM_STREAM_PLAYBACK && stm->other_stream) {
    int r = alsa_stream_stop(stm->other_stream);
    if (r != CUBEB_OK)
      return r;
  }

  pthread_mutex_lock(&ctx->mutex);
  while (stm->state == PROCESSING) {
    r = pthread_cond_wait(&stm->cond, &ctx->mutex);
    assert(r == 0);
  }

  alsa_set_stream_state(stm, INACTIVE);
  pthread_mutex_unlock(&ctx->mutex);

  pthread_mutex_lock(&stm->mutex);
  WRAP(snd_pcm_pause)(stm->pcm, 1);
  pthread_mutex_unlock(&stm->mutex);

  return CUBEB_OK;
}

static int
alsa_stream_get_position(cubeb_stream * stm, uint64_t * position)
{
  snd_pcm_sframes_t delay;

  assert(stm && position);

  pthread_mutex_lock(&stm->mutex);

  delay = -1;
  if (WRAP(snd_pcm_state)(stm->pcm) != SND_PCM_STATE_RUNNING ||
      WRAP(snd_pcm_delay)(stm->pcm, &delay) != 0) {
    *position = stm->last_position;
    pthread_mutex_unlock(&stm->mutex);
    return CUBEB_OK;
  }

  assert(delay >= 0);

  *position = 0;
  if (stm->stream_position >= (snd_pcm_uframes_t)delay) {
    *position = stm->stream_position - delay;
  }

  stm->last_position = *position;

  pthread_mutex_unlock(&stm->mutex);
  return CUBEB_OK;
}

static int
alsa_stream_get_latency(cubeb_stream * stm, uint32_t * latency)
{
  snd_pcm_sframes_t delay;
  /* This function returns the delay in frames until a frame written using
     snd_pcm_writei is sent to the DAC. The DAC delay should be < 1ms anyways.
   */
  if (WRAP(snd_pcm_delay)(stm->pcm, &delay)) {
    return CUBEB_ERROR;
  }

  *latency = delay;

  return CUBEB_OK;
}

static int
alsa_stream_set_volume(cubeb_stream * stm, float volume)
{
  /* setting the volume using an API call does not seem very stable/supported */
  pthread_mutex_lock(&stm->mutex);
  stm->volume = volume;
  pthread_mutex_unlock(&stm->mutex);

  return CUBEB_OK;
}

static int
alsa_enumerate_devices(cubeb * context, cubeb_device_type type,
                       cubeb_device_collection * collection)
{
  void **hints = NULL;
  void **hint;
  char *name = NULL;
  char *io = NULL;
  char *desc = NULL;
  cubeb_device_info * devinfop = NULL;
  int collection_cnt = 0;
  int r;

  if (!context)
    return CUBEB_ERROR;

  /* Get device name hints from ALSA */
  r = WRAP(snd_device_name_hint)(-1, "pcm", &hints);
  if (r < 0) {
    LOG("Failed to get device name hints: %d", r);
    return CUBEB_ERROR;
  }

  /* Count devices first */
  for (hint = hints; *hint != NULL; hint++) {
    name = WRAP(snd_device_name_get_hint)(*hint, "NAME");
    if (!name)
      continue;

    io = WRAP(snd_device_name_get_hint)(*hint, "IOID");

    /* Filter by device type */
    if (type & CUBEB_DEVICE_TYPE_INPUT && io && strcmp(io, "Output") == 0) {
      free(name);
      if (io) free(io);
      continue;
    }
    if (type & CUBEB_DEVICE_TYPE_OUTPUT && io && strcmp(io, "Input") == 0) {
      free(name);
      if (io) free(io);
      continue;
    }

    free(name);
    if (io) free(io);
    collection_cnt++;
  }

  if (collection_cnt == 0) {
    WRAP(snd_device_name_free_hint)(hints);
    return CUBEB_OK;
  }

  devinfop = calloc(collection_cnt, sizeof(cubeb_device_info));
  if (!devinfop) {
    WRAP(snd_device_name_free_hint)(hints);
    return CUBEB_ERROR;
  }

  collection_cnt = 0;
  for (hint = hints; *hint != NULL; hint++) {
    snd_pcm_t * pcm = NULL;
    snd_pcm_hw_params_t * hw_params;
    snd_pcm_stream_t stream_type;
    cubeb_device_info cdi = {0};
    uint32_t min_rate, max_rate;
    uint32_t min_channels, max_channels;
    int dir;

    name = WRAP(snd_device_name_get_hint)(*hint, "NAME");
    if (!name)
      continue;

    io = WRAP(snd_device_name_get_hint)(*hint, "IOID");
    desc = WRAP(snd_device_name_get_hint)(*hint, "DESC");

    /* Filter by device type */
    if (type & CUBEB_DEVICE_TYPE_INPUT && io && strcmp(io, "Output") == 0) {
      goto cleanup_hint;
    }
    if (type & CUBEB_DEVICE_TYPE_OUTPUT && io && strcmp(io, "Input") == 0) {
      goto cleanup_hint;
    }

    /* Determine stream type */
    if (io && strcmp(io, "Input") == 0) {
      stream_type = SND_PCM_STREAM_CAPTURE;
      cdi.type = CUBEB_DEVICE_TYPE_INPUT;
    } else if (io && strcmp(io, "Output") == 0) {
      stream_type = SND_PCM_STREAM_PLAYBACK;
      cdi.type = CUBEB_DEVICE_TYPE_OUTPUT;
    } else {
      /* Try both if IOID is not specified */
      stream_type = (type & CUBEB_DEVICE_TYPE_OUTPUT) ?
                     SND_PCM_STREAM_PLAYBACK : SND_PCM_STREAM_CAPTURE;
      cdi.type = (type & CUBEB_DEVICE_TYPE_OUTPUT) ?
                 CUBEB_DEVICE_TYPE_OUTPUT : CUBEB_DEVICE_TYPE_INPUT;
    }

    /* Open device to query capabilities */
    r = WRAP(snd_pcm_open)(&pcm, name, stream_type, SND_PCM_NONBLOCK);
    if (r < 0) {
      LOG("Failed to open device %s: %d", name, r);
      goto cleanup_hint;
    }

    snd_pcm_hw_params_alloca(&hw_params);
    r = WRAP(snd_pcm_hw_params_any)(pcm, hw_params);
    if (r < 0) {
      LOG("Failed to get hw params for device %s: %d", name, r);
      WRAP(snd_pcm_close)(pcm);
      goto cleanup_hint;
    }

    /* Query format capabilities */
    cdi.format = 0;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_S16_LE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_S16LE;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_S16_BE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_S16BE;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_S32_LE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_S32LE;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_S32_BE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_S32BE;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_FLOAT_LE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_F32LE;
    if (WRAP(snd_pcm_hw_params_test_format)(pcm, hw_params, SND_PCM_FORMAT_FLOAT_BE) == 0)
      cdi.format |= CUBEB_DEVICE_FMT_F32BE;

    /* Set default format - prefer S32 for high-quality audio */
#if defined(WORDS_BIGENDIAN) || defined(__BIG_ENDIAN__)
    if (cdi.format & CUBEB_DEVICE_FMT_S32BE)
      cdi.default_format = CUBEB_DEVICE_FMT_S32BE;
    else if (cdi.format & CUBEB_DEVICE_FMT_S16BE)
      cdi.default_format = CUBEB_DEVICE_FMT_S16BE;
    else if (cdi.format & CUBEB_DEVICE_FMT_F32BE)
      cdi.default_format = CUBEB_DEVICE_FMT_F32BE;
    else
      cdi.default_format = CUBEB_DEVICE_FMT_S16BE;
#else
    if (cdi.format & CUBEB_DEVICE_FMT_S32LE)
      cdi.default_format = CUBEB_DEVICE_FMT_S32LE;
    else if (cdi.format & CUBEB_DEVICE_FMT_S16LE)
      cdi.default_format = CUBEB_DEVICE_FMT_S16LE;
    else if (cdi.format & CUBEB_DEVICE_FMT_F32LE)
      cdi.default_format = CUBEB_DEVICE_FMT_F32LE;
    else
      cdi.default_format = CUBEB_DEVICE_FMT_S16LE;
#endif

    /* Query rate range */
    r = WRAP(snd_pcm_hw_params_get_rate_min)(hw_params, &min_rate, &dir);
    if (r < 0)
      min_rate = 44100;
    r = WRAP(snd_pcm_hw_params_get_rate_max)(hw_params, &max_rate, &dir);
    if (r < 0)
      max_rate = 48000;

    /* Query channel range */
    r = WRAP(snd_pcm_hw_params_get_channels_min)(hw_params, &min_channels);
    if (r < 0)
      min_channels = 1;
    r = WRAP(snd_pcm_hw_params_get_channels_max)(hw_params, &max_channels);
    if (r < 0)
      max_channels = 2;

    /* Get default rate */
    r = WRAP(snd_pcm_hw_params_get_rate)(hw_params, &cdi.default_rate, &dir);
    if (r < 0)
      cdi.default_rate = 44100;

    WRAP(snd_pcm_close)(pcm);

    /* Fill device info */
    cdi.device_id = strdup(name);
    cdi.devid = (cubeb_devid)cdi.device_id;
    cdi.friendly_name = desc ? strdup(desc) : strdup(name);
    cdi.group_id = strdup(name);
    cdi.vendor_name = NULL;
    cdi.state = CUBEB_DEVICE_STATE_ENABLED;
    cdi.preferred = CUBEB_DEVICE_PREF_NONE;
    cdi.max_channels = max_channels;
    cdi.min_rate = min_rate;
    cdi.max_rate = max_rate;
    cdi.latency_lo = 0;
    cdi.latency_hi = 0;

    if (!cdi.device_id || !cdi.friendly_name || !cdi.group_id) {
      free((void *)cdi.device_id);
      free((void *)cdi.friendly_name);
      free((void *)cdi.group_id);
      goto cleanup_hint;
    }

    devinfop[collection_cnt++] = cdi;

cleanup_hint:
    free(name);
    if (io) free(io);
    if (desc) free(desc);
  }

  WRAP(snd_device_name_free_hint)(hints);

  collection->device = devinfop;
  collection->count = collection_cnt;

  return CUBEB_OK;
}

static int
alsa_device_collection_destroy(cubeb * context,
                               cubeb_device_collection * collection)
{
  size_t i;

  (void)context;

  for (i = 0; i < collection->count; ++i) {
    free((void *)collection->device[i].device_id);
    free((void *)collection->device[i].friendly_name);
    free((void *)collection->device[i].group_id);
    free((void *)collection->device[i].vendor_name);
  }
  free(collection->device);
  return CUBEB_OK;
}

static struct cubeb_ops const alsa_ops = {
    .init = alsa_init,
    .get_backend_id = alsa_get_backend_id,
    .get_max_channel_count = alsa_get_max_channel_count,
    .get_min_latency = alsa_get_min_latency,
    .get_preferred_sample_rate = alsa_get_preferred_sample_rate,
    .get_supported_input_processing_params = NULL,
    .enumerate_devices = alsa_enumerate_devices,
    .device_collection_destroy = alsa_device_collection_destroy,
    .destroy = alsa_destroy,
    .stream_init = alsa_stream_init,
    .stream_destroy = alsa_stream_destroy,
    .stream_start = alsa_stream_start,
    .stream_stop = alsa_stream_stop,
    .stream_get_position = alsa_stream_get_position,
    .stream_get_latency = alsa_stream_get_latency,
    .stream_get_input_latency = NULL,
    .stream_set_volume = alsa_stream_set_volume,
    .stream_set_name = NULL,
    .stream_get_current_device = NULL,
    .stream_set_input_mute = NULL,
    .stream_set_input_processing_params = NULL,
    .stream_device_destroy = NULL,
    .stream_register_device_changed_callback = NULL,
    .register_device_collection_changed = NULL};

$ cat 0001-Add-S32-format-to-the-Firefox-API.patch
From 80bbf447a62e6136f54c4938b99487135383276b Mon Sep 17 00:00:00 2001
From: Devuan
Date: Tue, 7 Jul 2026 22:35:36 +0200
Subject: [PATCH 1/2] Add S32 format to the Firefox API

- Add FMT_S32LE and FMT_S32BE constants to nsIAudioDeviceInfo.idl
- Update AudioDeviceInfo.cpp assertions to accept S32 formats
- Add S32 format conversion in CubebDeviceEnumerator.cpp
- Add local S32 format definitions for external cubeb support
- Update aboutSupport.js to display S32 format information
---
 dom/media/AudioDeviceInfo.cpp              |  5 +++--
 dom/media/CubebUtils.cpp                   |  1 +
 dom/media/nsIAudioDeviceInfo.idl           |  4 +++-
 dom/media/webrtc/CubebDeviceEnumerator.cpp | 14 ++++++++++++++
 toolkit/content/aboutSupport.js            |  4 ++++
 5 files changed, 25 insertions(+), 3 deletions(-)

diff --git a/dom/media/AudioDeviceInfo.cpp b/dom/media/AudioDeviceInfo.cpp
index 072dd43d4ec1..a09e0adf71c3 100644
--- a/dom/media/AudioDeviceInfo.cpp
+++ b/dom/media/AudioDeviceInfo.cpp
@@ -49,10 +49,11 @@ AudioDeviceInfo::AudioDeviceInfo(
       mPreferred == PREF_NONE || mPreferred == PREF_ALL ||
           mPreferred & (PREF_MULTIMEDIA | PREF_VOICE | PREF_NOTIFICATION),
       "Wrong preferred value");
-  MOZ_ASSERT(mSupportedFormat & (FMT_S16LE | FMT_S16BE | FMT_F32LE | FMT_F32BE),
+  MOZ_ASSERT(mSupportedFormat & (FMT_S16LE | FMT_S16BE | FMT_F32LE | FMT_F32BE | FMT_S32LE | FMT_S32BE),
              "Wrong supported format");
   MOZ_ASSERT(mDefaultFormat == FMT_S16LE || mDefaultFormat == FMT_S16BE ||
-                 mDefaultFormat == FMT_F32LE || mDefaultFormat == FMT_F32BE,
+                 mDefaultFormat == FMT_F32LE || mDefaultFormat == FMT_F32BE ||
+                 mDefaultFormat == FMT_S32LE || mDefaultFormat == FMT_S32BE,
              "Wrong default format");
 }

diff --git a/dom/media/CubebUtils.cpp b/dom/media/CubebUtils.cpp
index 72551b795af3..a9edab7bc358 100644
--- a/dom/media/CubebUtils.cpp
+++ b/dom/media/CubebUtils.cpp
@@ -143,6 +143,7 @@ MOZ_RUNINIT std::unordered_map<std::string, BackendLabel>
         {"alsa", BackendLabel::eAlsa},
         {"jack", BackendLabel::eJack},
         {"oss", BackendLabel::eOss},
+        {"oss-fft", BackendLabel::eOss},
         {"pulse", BackendLabel::ePulse},
         {"pulse-rust", BackendLabel::ePulseRust},
         {"sndio", BackendLabel::eSndio},
diff --git a/dom/media/nsIAudioDeviceInfo.idl b/dom/media/nsIAudioDeviceInfo.idl
index 0458ec1eb927..59d90a0ad3f5 100644
--- a/dom/media/nsIAudioDeviceInfo.idl
+++ b/dom/media/nsIAudioDeviceInfo.idl
@@ -33,11 +33,13 @@ interface nsIAudioDeviceInfo : nsISupports
   const unsigned short PREF_ALL           = 0x0F;
   readonly attribute unsigned short preferred;

-  // supported format, default format: S16LE/S16BE/F32LE/F32BE
+  // supported format, default format: S16LE/S16BE/F32LE/F32BE/S32LE/S32BE
   const unsigned short FMT_S16LE = 0x0010;
   const unsigned short FMT_S16BE = 0x0020;
   const unsigned short FMT_F32LE = 0x1000;
   const unsigned short FMT_F32BE = 0x2000;
+  const unsigned short FMT_S32LE = 0x0040;
+  const unsigned short FMT_S32BE = 0x0080;
   readonly attribute unsigned short supportedFormat;
   readonly attribute unsigned short defaultFormat;

diff --git a/dom/media/webrtc/CubebDeviceEnumerator.cpp b/dom/media/webrtc/CubebDeviceEnumerator.cpp
index 6e1520c3c714..0d2043cb497c 100644
--- a/dom/media/webrtc/CubebDeviceEnumerator.cpp
+++ b/dom/media/webrtc/CubebDeviceEnumerator.cpp
@@ -17,6 +17,14 @@
 #  include "mozilla/mscom/EnsureMTA.h"
 #endif

+// S32 format constants for external cubeb libraries that support them
+#ifndef CUBEB_DEVICE_FMT_S32LE
+#define CUBEB_DEVICE_FMT_S32LE 0x0040
+#endif
+#ifndef CUBEB_DEVICE_FMT_S32BE
+#define CUBEB_DEVICE_FMT_S32BE 0x0080
+#endif
+
 namespace mozilla {

 using namespace CubebUtils;
@@ -183,6 +191,12 @@ static uint16_t ConvertCubebFormat(cubeb_device_fmt aFormat) {
   if (aFormat & CUBEB_DEVICE_FMT_F32BE) {
     format |= nsIAudioDeviceInfo::FMT_F32BE;
   }
+  if (aFormat & CUBEB_DEVICE_FMT_S32LE) {
+    format |= nsIAudioDeviceInfo::FMT_S32LE;
+  }
+  if (aFormat & CUBEB_DEVICE_FMT_S32BE) {
+    format |= nsIAudioDeviceInfo::FMT_S32BE;
+  }
   return format;
 }

diff --git a/toolkit/content/aboutSupport.js b/toolkit/content/aboutSupport.js
index 388f8048201f..af6e396feb7d 100644
--- a/toolkit/content/aboutSupport.js
+++ b/toolkit/content/aboutSupport.js
@@ -974,6 +974,8 @@ var snapshotFormatters = {
       formats[deviceInfo.FMT_S16BE] = "S16BE";
       formats[deviceInfo.FMT_F32LE] = "F32LE";
       formats[deviceInfo.FMT_F32BE] = "F32BE";
+      formats[deviceInfo.FMT_S32LE] = "S32LE";
+      formats[deviceInfo.FMT_S32BE] = "S32BE";

       function toPreferredString(preferred) {
         if (preferred == deviceInfo.PREF_NONE) {
@@ -1001,6 +1003,8 @@ var snapshotFormatters = {
           deviceInfo.FMT_S16BE,
           deviceInfo.FMT_F32LE,
           deviceInfo.FMT_F32BE,
+          deviceInfo.FMT_S32LE,
+          deviceInfo.FMT_S32BE,
         ]) {
           if (dev.supportedFormat & fmt) {
             str += " " + formats[fmt];
--
2.39.5

$ cat 0002-Add-S32-format-to-the-Cubeb-API.patch
From f8d402971731b6729daf47624fe74a7e7466ee24 Mon Sep 17 00:00:00 2001
From: Devuan
Date: Thu, 9 Jul 2026 17:48:56 +0200
Subject: [PATCH 2/2] Add S32 format to the Cubeb API

- Add CUBEB_DEVICE_FMT_S32LE and CUBEB_DEVICE_FMT_S32BE constants to API
- Update log_device function to handle S32 formats in logging
- Update test_devices to handle S32 format display
---
 media/libcubeb/include/cubeb/cubeb.h | 17 ++++++++++++-----
 media/libcubeb/src/cubeb.c           | 23 +++++++++++++++++++++++
 media/libcubeb/test/test_devices.cpp | 10 ++++++++++
 3 files changed, 45 insertions(+), 5 deletions(-)

diff --git a/media/libcubeb/include/cubeb/cubeb.h b/media/libcubeb/include/cubeb/cubeb.h
index ff2f8b7b987d..322230a2df11 100644
--- a/media/libcubeb/include/cubeb/cubeb.h
+++ b/media/libcubeb/include/cubeb/cubeb.h
@@ -340,6 +340,8 @@ typedef enum {
 typedef enum {
   CUBEB_DEVICE_FMT_S16LE = 0x0010, /**< 16-bit integers, Little Endian. */
   CUBEB_DEVICE_FMT_S16BE = 0x0020, /**< 16-bit integers, Big Endian. */
+  CUBEB_DEVICE_FMT_S32LE = 0x0040, /**< 32-bit integers, Little Endian. */
+  CUBEB_DEVICE_FMT_S32BE = 0x0080, /**< 32-bit integers, Big Endian. */
   CUBEB_DEVICE_FMT_F32LE = 0x1000, /**< 32-bit floating point, Little Endian. */
   CUBEB_DEVICE_FMT_F32BE = 0x2000  /**< 32-bit floating point, Big Endian. */
 } cubeb_device_fmt;
@@ -347,25 +349,30 @@ typedef enum {
 #if defined(WORDS_BIGENDIAN) || defined(__BIG_ENDIAN__)
 /** 16-bit integers, native endianess, when on a Big Endian environment. */
 #define CUBEB_DEVICE_FMT_S16NE CUBEB_DEVICE_FMT_S16BE
-/** 32-bit floating points, native endianess, when on a Big Endian environment.
- */
+/** 32-bit integers, native endianess, when on a Big Endian environment. */
+#define CUBEB_DEVICE_FMT_S32NE CUBEB_DEVICE_FMT_S32BE
+/** 32-bit floating points, native endianess, when on a Big Endian environment. */
 #define CUBEB_DEVICE_FMT_F32NE CUBEB_DEVICE_FMT_F32BE
 #else
 /** 16-bit integers, native endianess, when on a Little Endian environment. */
 #define CUBEB_DEVICE_FMT_S16NE CUBEB_DEVICE_FMT_S16LE
-/** 32-bit floating points, native endianess, when on a Little Endian
- *  environment. */
+/** 32-bit integers, native endianess, when on a Little Endian environment. */
+#define CUBEB_DEVICE_FMT_S32NE CUBEB_DEVICE_FMT_S32LE
+/** 32-bit floating points, native endianess, when on a Little Endian environment. */
 #define CUBEB_DEVICE_FMT_F32NE CUBEB_DEVICE_FMT_F32LE
 #endif
 /** All the 16-bit integers types. */
 #define CUBEB_DEVICE_FMT_S16_MASK                                              \
   (CUBEB_DEVICE_FMT_S16LE | CUBEB_DEVICE_FMT_S16BE)
+/** All the 32-bit integers types. */
+#define CUBEB_DEVICE_FMT_S32_MASK                                              \
+  (CUBEB_DEVICE_FMT_S32LE | CUBEB_DEVICE_FMT_S32BE)
 /** All the 32-bit floating points types. */
 #define CUBEB_DEVICE_FMT_F32_MASK                                              \
   (CUBEB_DEVICE_FMT_F32LE | CUBEB_DEVICE_FMT_F32BE)
 /** All the device formats types. */
 #define CUBEB_DEVICE_FMT_ALL                                                   \
-  (CUBEB_DEVICE_FMT_S16_MASK | CUBEB_DEVICE_FMT_F32_MASK)
+  (CUBEB_DEVICE_FMT_S16_MASK | CUBEB_DEVICE_FMT_S32_MASK | CUBEB_DEVICE_FMT_F32_MASK)

 /** Channel type for a `cubeb_stream`. Depending on the backend and platform
  * used, this can control inter-stream interruption, ducking, and volume
diff --git a/media/libcubeb/src/cubeb.c b/media/libcubeb/src/cubeb.c
index 4fdead389354..1ca8582bab71 100644
--- a/media/libcubeb/src/cubeb.c
+++ b/media/libcubeb/src/cubeb.c
@@ -75,6 +75,10 @@ opensl_init(cubeb ** context, char const * context_name);
 int
 oss_init(cubeb ** context, char const * context_name);
 #endif
+#if defined(USE_OSS_FFT)
+int
+oss_fft_init(cubeb ** context, char const * context_name);
+#endif
 #if defined(USE_AAUDIO)
 int
 aaudio_init(cubeb ** context, char const * context_name);
@@ -195,6 +199,10 @@ cubeb_init(cubeb ** context, char const * context_name,
     } else if (!strcmp(backend_name, "oss")) {
 #if defined(USE_OSS)
       init_oneshot = oss_init;
+#endif
+} else if (!strcmp(backend_name, "oss-fft")) {
+#if defined(USE_OSS_FFT)
+  init_oneshot = oss_fft_init;
 #endif
     } else if (!strcmp(backend_name, "aaudio")) {
 #if defined(USE_AAUDIO)
@@ -237,6 +245,9 @@ cubeb_init(cubeb ** context, char const * context_name,
 #if defined(USE_OSS)
       oss_init,
 #endif
+#if defined(USE_OSS_FFT)
+  oss_fft_init,
+#endif
 #if defined(USE_AUDIOUNIT_RUST)
       audiounit_rust_init,
 #endif
@@ -690,6 +701,12 @@ log_device(cubeb_device_info * device_info)
   case CUBEB_DEVICE_FMT_F32BE:
     devdeffmt = "F32BE";
     break;
+	case CUBEB_DEVICE_FMT_S32LE:
+		devdeffmt = "S32LE";
+		break;
+	case CUBEB_DEVICE_FMT_S32BE:
+		devdeffmt = "S32BE";
+		break;
   default:
     devdeffmt = "unknown?";
     break;
@@ -707,6 +724,12 @@ log_device(cubeb_device_info * device_info)
   if (device_info->format & CUBEB_DEVICE_FMT_F32BE) {
     strcat(devfmts, " F32BE");
   }
+  if (device_info->format & CUBEB_DEVICE_FMT_S32LE) {
+    strcat(devfmts, " S32LE");
+  }
+  if (device_info->format & CUBEB_DEVICE_FMT_S32BE) {
+    strcat(devfmts, " S32BE");
+  }

   LOG("DeviceID: \"%s\"%s\n"
       "\tName:\t\"%s\"\n"
diff --git a/media/libcubeb/test/test_devices.cpp b/media/libcubeb/test/test_devices.cpp
index d0eab2da67e6..4a8da1a4113b 100644
--- a/media/libcubeb/test/test_devices.cpp
+++ b/media/libcubeb/test/test_devices.cpp
@@ -79,6 +79,12 @@ print_device_info(cubeb_device_info * info, FILE * f)
   case CUBEB_DEVICE_FMT_F32BE:
     devdeffmt = "F32BE";
     break;
+  case CUBEB_DEVICE_FMT_S32LE:  // Add this
+    devdeffmt = "S32LE";
+    break;
+  case CUBEB_DEVICE_FMT_S32BE:  // Add this
+    devdeffmt = "S32BE";
+    break;
   default:
     devdeffmt = "unknown?";
     break;
@@ -92,6 +98,10 @@ print_device_info(cubeb_device_info * info, FILE * f)
     strcat(devfmts, " F32LE");
   if (info->format & CUBEB_DEVICE_FMT_F32BE)
     strcat(devfmts, " F32BE");
+	if (info->format & CUBEB_DEVICE_FMT_S32LE)  // Add this
+		strcat(devfmts, " S32LE");
+	if (info->format & CUBEB_DEVICE_FMT_S32BE)  // Add this
+		strcat(devfmts, " S32BE");

   fprintf(f,
           "dev: \"%s\"%s\n"
--
2.39.5

$ firefox-dev about:support
...
Name 	Firefox Developer Edition
Version 	154.0a1
...
Update Channel 	aurora
User Agent 	Mozilla/5.0 (X11; Linux x86_64; rv:154.0) Gecko/20100101 Firefox/154.0
...
Application Binary 	/usr/lib/firefox-dev/firefox-dev
Profile Directory 	$HOME/.firefox-dev/uf30avtz.dev-edition-default
...
Audio Backend: alsa
Max Channels: 64
Preferred Sample Rate: 44100
Roundtrip latency (standard deviation): NaNms (NaN)
...
Output Devices
Name: Group, Vendor, State, Preferred, Format, Channels, Rate, Latency
Discard all samples (playback) or generate zero samples (capture): null, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 1073741823, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Libav/FFmpeg Library: lavrate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Samplerate Library: samplerate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Speex Resampler: speexrate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Bluetooth Audio: bluealsa, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
Plugin using Speex DSP (resample, agc, denoise, echo, dereverb): speex, Enabled, None, default: S16LE, support: S16LE, 1, default: 44100, support: 4000 - 4294967295, 0 - 0
Plugin for channel upmix (4,6,8): upmix, Enabled, None, default: S16LE, support: S16LE, 8, default: 44100, support: 4000 - 4294967295, 0 - 0
Plugin for channel downmix (stereo) with a simple spacialization: vdownmix, Enabled, None, default: S16LE, support: S16LE, 6, default: 44100, support: 4000 - 4294967295, 0 - 0
Default device: default, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Direct hardware device without any conversions: hw:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, HDMI 0 Direct hardware device without any conversions: hw:CARD=PCH,DEV=3, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 1 Direct hardware device without any conversions: hw:CARD=PCH,DEV=7, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 2 Direct hardware device without any conversions: hw:CARD=PCH,DEV=8, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 3 Direct hardware device without any conversions: hw:CARD=PCH,DEV=9, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog Hardware device with all software conversions: plughw:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, HDMI 0 Hardware device with all software conversions: plughw:CARD=PCH,DEV=3, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, HDMI 1 Hardware device with all software conversions: plughw:CARD=PCH,DEV=7, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, HDMI 2 Hardware device with all software conversions: plughw:CARD=PCH,DEV=8, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, HDMI 3 Hardware device with all software conversions: plughw:CARD=PCH,DEV=9, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Default Audio Device: sysdefault:CARD=PCH, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Front output / input: front:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog 4.0 Surround output to Front and Rear speakers: surround40:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog 5.1 Surround output to Front, Center, Rear and Subwoofer speakers: surround51:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog 7.1 Surround output to Front, Center, Side, Rear and Woofer speakers: surround71:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, HDMI 0 HDMI Audio Output: hdmi:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 1 HDMI Audio Output: hdmi:CARD=PCH,DEV=1, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 2 HDMI Audio Output: hdmi:CARD=PCH,DEV=2, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, HDMI 3 HDMI Audio Output: hdmi:CARD=PCH,DEV=3, Enabled, None, default: S32LE, support: S16LE S32LE, 8, default: 44100, support: 32000 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog Direct sample mixing device: dmix:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0
HDA Intel PCH, HDMI 0 Direct sample mixing device: dmix:CARD=PCH,DEV=3, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0
HDA Intel PCH, HDMI 1 Direct sample mixing device: dmix:CARD=PCH,DEV=7, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0
HDA Intel PCH, HDMI 2 Direct sample mixing device: dmix:CARD=PCH,DEV=8, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0
HDA Intel PCH, HDMI 3 Direct sample mixing device: dmix:CARD=PCH,DEV=9, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0
Input Devices
Name: Group, Vendor, State, Preferred, Format, Channels, Rate, Latency
Discard all samples (playback) or generate zero samples (capture): null, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 1073741823, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Libav/FFmpeg Library: lavrate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Samplerate Library: samplerate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Rate Converter Plugin Using Speex Resampler: speexrate, Enabled, None, default: S32LE, support: S16LE S16BE S32LE S32BE, 10000, default: 44100, support: 1 - 4294967295, 0 - 0
Plugin using Speex DSP (resample, agc, denoise, echo, dereverb): speex, Enabled, None, default: S16LE, support: S16LE, 1, default: 44100, support: 4000 - 4294967295, 0 - 0
Plugin for channel upmix (4,6,8): upmix, Enabled, None, default: S16LE, support: S16LE, 8, default: 44100, support: 4000 - 4294967295, 0 - 0
Plugin for channel downmix (stereo) with a simple spacialization: vdownmix, Enabled, None, default: S16LE, support: S16LE, 6, default: 44100, support: 4000 - 4294967295, 0 - 0
Default device: default, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Direct hardware device without any conversions: hw:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog Hardware device with all software conversions: plughw:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Default Audio Device: sysdefault:CARD=PCH, Enabled, None, default: S32LE, support: S16LE S16BE F32LE F32BE S32LE S32BE, 10000, default: 44100, support: 4000 - 4294967295, 0 - 0
HDA Intel PCH, 92HD95 Analog Front output / input: front:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S16LE S32LE, 2, default: 44100, support: 44100 - 192000, 0 - 0
HDA Intel PCH, 92HD95 Analog Direct sample snooping device: dsnoop:CARD=PCH,DEV=0, Enabled, None, default: S32LE, support: S32LE, 2, default: 48000, support: 48000 - 48000, 0 - 0

Application → ALSA Library (libasound) → hw plugin → ioctl → Kernel Driver → Hardware

ii  x11proto-dev                         2025.1-1+xlibre1                             all          X11 extension protocols and auxiliary headers
ii  xlibre                               1:7.8+5                                      amd64        XLibre X Window System
ii  xlibre-archive-keyring               1.0.0-1                                      all          OpenPGP archive certificates of XLibre
ii  xlibre-x11-common                    1:7.8+5                                      all          X Window System (X.Org) infrastructure
ii  xlibre-xutils                        1:7.8+5                                      all          X Window System utility programs metapackage
ii  xserver-xlibre                       1:7.8+5                                      amd64        XLibre X server
ii  xserver-xlibre-common                2:25.2.0-3                                   all          common files used by various X servers
ii  xserver-xlibre-core                  2:25.2.0-3                                   amd64        XLibre X server - core server
ii  xserver-xlibre-input-all             1:7.8+5                                      amd64        XLibre X server -- input driver metapackage
ii  xserver-xlibre-input-libinput        1:25.0.1-1                                   amd64        XLibre X server -- libinput input driver
ii  xserver-xlibre-video-all             1:7.8+5                                      amd64        XLibre X server -- output driver metapackage
ii  xserver-xlibre-video-amdgpu          25.1.1-3                                     amd64        XLibre X server -- AMDGPU display driver
ii  xserver-xlibre-video-ati             1:25.0.1-1                                   amd64        XLibre X server -- AMD/ATI display driver wrapper
ii  xserver-xlibre-video-fbdev           2:25.0.0-1                                   amd64        XLibre X server -- fbdev display driver
ii  xserver-xlibre-video-nouveau         2:25.0.0-1                                   amd64        XLibre X server -- Nouveau display driver
ii  xserver-xlibre-video-qxl             1:25.0.0-1                                   amd64        XLibre X server -- QXL display driver
ii  xserver-xlibre-video-radeon          1:25.0.1-1                                   amd64        XLibre X server -- AMD/ATI Radeon display driver
ii  xserver-xlibre-video-vesa            2:25.0.0-1                                   amd64        XLibre X server -- VESA display driver
ii  xserver-xlibre-video-vmware          2:25.0.0-1                                   amd64        XLibre X server -- VMware display driver
ii  xserver-xlibre-xephyr                2:25.2.0-3                                   amd64        nested X server

[Settings]
gtk-primary-button-warps-slider = false

sudo dmesg | grep amdgpu
[sudo] password for :
[   15.624597] amdgpu: Virtual CRAT table created for CPU
[   15.624676] amdgpu: Topology: Add CPU node
[   15.625191] amdgpu 0000:00:01.0: initializing kernel modesetting (CARRIZO 0x1002:0x9874 0x17AA:0x5120 0xC9).
[   15.661524] amdgpu 0000:00:01.0: register mmio base: 0xF0F00000
[   15.661532] amdgpu 0000:00:01.0: register mmio size: 262144
[   15.662084] amdgpu 0000:00:01.0: detected ip block number 0 <common_v1_0_0> (vi_common)
[   15.662095] amdgpu 0000:00:01.0: detected ip block number 1 <gmc_v8_0_0> (gmc_v8_0)
[   15.662110] amdgpu 0000:00:01.0: detected ip block number 2 <ih_v3_0_0> (cz_ih)
[   15.662114] amdgpu 0000:00:01.0: detected ip block number 3 <gfx_v8_0_0> (gfx_v8_0)
[   15.662117] amdgpu 0000:00:01.0: detected ip block number 4 <sdma_v3_0_0> (sdma_v3_0)
[   15.662120] amdgpu 0000:00:01.0: detected ip block number 5 <smu_v1_0_0> (powerplay)
[   15.662123] amdgpu 0000:00:01.0: detected ip block number 6 <dce_v1_0_0> (dm)
[   15.662126] amdgpu 0000:00:01.0: detected ip block number 7 <uvd_v6_0_0> (uvd_v6_0)
[   15.662129] amdgpu 0000:00:01.0: detected ip block number 8 <vce_v3_1_0> (vce_v3_0)
[   15.662132] amdgpu 0000:00:01.0: detected ip block number 9 <acp_v2_2_0> (acp_ip)
[   15.674451] amdgpu 0000:00:01.0: Fetched VBIOS from ROM BAR
[   15.674456] amdgpu 0000:00:01.0: [drm] ATOM BIOS: 113-C75100-031
[   15.678025] amdgpu 0000:00:01.0: [drm] UVD is enabled in physical mode
[   15.680078] amdgpu 0000:00:01.0: Found VCE firmware Version: 52.4 Binary ID: 3
[   15.680087] amdgpu 0000:00:01.0: [drm] VCE enabled in physical mode
[   15.680705] amdgpu 0000:00:01.0: vgaarb: deactivate vga console
[   15.680710] amdgpu 0000:00:01.0: Trusted Memory Zone (TMZ) feature not supported
[   15.680714] amdgpu 0000:00:01.0: PCIE atomic ops is not supported
[   15.680764] amdgpu 0000:00:01.0: vm size is 64 GB, 2 levels, block size is 10-bit, fragment size is 9-bit
[   15.680774] amdgpu 0000:00:01.0: VRAM: 1024M 0x000000F400000000 - 0x000000F43FFFFFFF (1024M used)
[   15.680778] amdgpu 0000:00:01.0: GART: 1024M 0x000000FF00000000 - 0x000000FF3FFFFFFF
[   15.680793] amdgpu 0000:00:01.0: [drm] Detected VRAM RAM=1024M, BAR=1024M
[   15.680796] amdgpu 0000:00:01.0: [drm] RAM width 128bits UNKNOWN
[   15.681051] amdgpu 0000:00:01.0:  1024M of VRAM memory ready
[   15.681056] amdgpu 0000:00:01.0:  7449M of GTT memory ready.
[   15.681101] amdgpu 0000:00:01.0: [drm] GART: num cpu pages 262144, num gpu pages 262144
[   15.681666] amdgpu 0000:00:01.0: [drm] PCIE GART of 1024M enabled (table at 0x000000F400E00000).
[   15.688241] amdgpu: hwmgr_sw_init smu backed is smu8_smu
[   15.690399] amdgpu 0000:00:01.0: [drm] Found UVD firmware Version: 1.91 Family ID: 11
[   15.690469] amdgpu 0000:00:01.0: [drm] UVD ENC is disabled
[   15.693026] amdgpu: smu version 27.18.00
[   15.699361] amdgpu 0000:00:01.0: [drm] Display Core v3.2.369 initialized on DCE 11.0
[   15.713298] snd_hda_intel 0000:00:01.1: bound 0000:00:01.0 (ops amdgpu_dm_audio_component_bind_ops [amdgpu])
[   15.754619] amdgpu 0000:00:01.0: [drm] Using ACPI provided EDID for eDP-1
[   15.785324] amdgpu 0000:00:01.0: [drm] UVD initialized successfully.
[   15.984828] amdgpu 0000:00:01.0: [drm] VCE initialized successfully.
[   15.985930] amdgpu 0000:00:01.0: SE 1, SH per SE 1, CU per SH 8, active_cu_number 6
[   15.987124] amdgpu: pp_dpm_get_sclk_od was not implemented.
[   15.987128] amdgpu: pp_dpm_get_mclk_od was not implemented.
[   15.987316] amdgpu 0000:00:01.0: Runtime PM not available
[   15.996967] amdgpu 0000:00:01.0: [drm] Using custom brightness curve
[   15.997483] amdgpu 0000:00:01.0: [drm] Registered 3 planes with drm panic
[   16.016758] [drm] Initialized amdgpu 3.64.0 for 0000:00:01.0 on minor 0
[   16.023676] fbcon: amdgpudrmfb (fb0) is primary device
[   16.699733] amdgpu 0000:00:01.0: [drm] fb0: amdgpudrmfb frame buffer device

00:01.0 VGA compatible controller: Advanced Micro Devices, Inc. [AMD/ATI] Wani [Radeon R5/R6/R7 Graphics] (rev c9) (prog-if 00 [VGA controller])
        Subsystem: Lenovo Device 5120
        Control: I/O+ Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx+
        Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx-
        Latency: 0, Cache Line Size: 32 bytes
        Interrupts: pin B disabled, MSI(X) routed to IRQ 60
        IOMMU group: 0
        Region 0: Memory at e0000000 (64-bit, prefetchable) [size=256M]
        Region 2: Memory at f0000000 (64-bit, prefetchable) [size=8M]
        Region 4: I/O ports at 2000 [size=256]
        Region 5: Memory at f0f00000 (32-bit, non-prefetchable) [size=256K]
        Expansion ROM at 000c0000 [disabled] [size=128K]
        Capabilities: <access denied>
        Kernel driver in use: amdgpu
        Kernel modules: amdgpu
00: 02 10 74 98 07 04 10 00 c9 00 00 03 08 00 80 00
10: 0c 00 00 e0 00 00 00 00 0c 00 00 f0 00 00 00 00
20: 01 20 00 00 00 00 f0 f0 00 00 00 00 aa 17 20 51
30: 00 00 fe ff 48 00 00 00 00 00 00 00 0b 01 00 00
